HODA Series
Outdoor LED for FIX
  • only 83mm tickness,super slim
  • only 23kg/sqm,less 45% in weight
  • slience work with high precision
  • can do 90 degree in corner
  • hard connection with stable quality
  • Front/Rear maintenance
Parameter

Item HODA Series-Outdoor LED for FIX
Pixel Pitch P2.9 outdoor P3.9 outdoor P4.8 outdoor P6.25 outdoor P7.81 outdoor P10.42 outdoor
LED per pixel SMD1415 SMD1921 SMD1921 SMD2727 SMD2727 SMD2727
Pixel Density
(per sqm)
112896 65536 43264 25600 16384 9216
Module Dimension
(WxH/mm)
500x250 500x250 500x250 500x250 500x250 500x250
Module Resolution 168x84 pixels 128x64 pixels 104x52 pixels 80x40 pixels 64x32 pixels 48x24 pixels
Scan Rate 1/21 1/16 1/13 1/5 1/4 1/2
Cabinet Dimension
(WxHxD/mm)
1000x1000x83
1000x750x83
1000x500x83
1000x1000x83
1000x750x83
1000x500x83
1000x1000x83
1000x750x83
1000x500x83
1000x1000x83
1000x750x83
1000x500x83
1000x1000x83
1000x750x83
1000x500x83
1000x1000x83
1000x750x83
1000x500x83
Cabinet Resolution
(1000mm)
336x336 pixels 256x256 pixels 208x208 pixels 160x160 pixels 128x128 pixels 96x96 pixels
Weight(kgs) 23.5 23.5 23.5 23.5 23.5 23.5
Refresh Rate 1920/3840Hz 1920/3840Hz 1920/3840Hz 1920/3840Hz 1920/3840Hz 1920/3840Hz
View Angle(H/V) 140°/140° 140°/140° 140°/140° 140°/140° 140°/140° 140°/140°
Maintenance
Module(F/R)
PSU/RX(R)
Module(F/R)
PSU/RX(R)
Module(F/R)
PSU/RX(R)
Module(F/R)
PSU/RX(R)
Module(F/R)
PSU/RX(R)
Module(F/R)
PSU/RX(R)
Gray Scale 14-16bit 14-16bit 14-16bit 14-16bit 14-16bit 14-16bit
Brightness 4500-5500nits 4500-5500nits 4500-5500nits
5000-6000nits
6000-8000nits
5000-6000nits
6000-8000nits
5000-6000nits
6000-8000nits
Power Consumption
(Max/Avg)
800w/280w 800w/280w 800w/280w 800w/280w 800w/280w 800w/280w
Ingress Protection
(F/R)
IP65(F)/IP54(R) IP65(F)/IP54(R) IP65(F)/IP54(R) IP65(F)/IP54(R) IP65(F)/IP54(R) IP65(F)/IP54(R)
Lifetime(Hrs) 50000 50000 50000 50000 50000 50000
Working Temperature -20℃~+60℃ -20℃~+60℃ -20℃~+60℃ -20℃~+60℃ -20℃~+60℃ -20℃~+60℃

Download & Video
  • To ensure you can find the right solution for your projects,pls download the detail product information to know more.

    if you haven't find what you are looking for,pls contact with our team via sales@holiled.com.

Specification Download
